Multi Layer Dryer

Get a Price/Quote

MOQ : 1 Unit

Multi Layer Dryer Specification

Installation Guideline
Onsite Installation Supported

Motor Power
3 x 5.5 kW

Speed
Adjustable 0.1-2.5 m/min

Production Capacity
1000 kg/hour

Efficiency (%)
Over 90%

Model No
MLD-1000

Driven Type
Electric Driven

Frequency
50 Hz

Usage & Applications
Food Industry, Pharmaceutical, Chemical Drying, Vegetables & Fruits Drying

Temperature Range
30 - 150C

Accessories
Feeder, Conveyor Belts, Exhaust System, Control Cabinet

Automation Grade
Automatic

Type
Multi Layer Dryer

Material
Stainless Steel

Computerized
Yes

Automatic Grade
Automatic

Drive Type
Electric

Voltage
380 V

Power
22 kW

Weight (kg)
3500 kg

Dimension (L*W*H)
8000 x 2200 x 3000 mm

Color
Silver

Capacity
300-1000 kg/hr

Features
Uniform Drying, Energy Efficient, Low Noise Operation, Easy Maintenance, Adjustable Layers, Stainless Steel Construction

Surface Finish
Polished

Machine Type
Continuous Belt Dryer

Power Consumption
22 kW/hr

Insulation Material
High-Density Rock Wool

Air Flow Direction
Cross Flow/Parallel Flow

Number of Layers
5

Tray Size
Customized

Application Range
Vegetables, Fruits, Spices, Grains, Herbs

Heating Method
Hot Air Circulation

Noise Level
<70 dB

After Sales Service
Available

Safety Features
Overload Protection, Emergency Stop Button

Door Type
Double Sealed Doors

Multi Layer Dryer Trade Information

Minimum Order Quantity
1 Unit

Payment Terms
Cash in Advance (CID)

Supply Ability
10 Units Per Month

Delivery Time
30 Days

Main Domestic Market
All India

About Multi Layer Dryer

Total power : 144.2kw
Drive power(KW) : 1.5kw+1.5kw+1.5kw
Swing Spreader motor : 0.2 kw
Heating power : 120kw
Circulation fan power : 3kw*6
Dehumidifying fan: : 0.75kw*2
Belt width : 1000mm
Capacity : 400-500kg/h
Dimension(m) : 11.0x1.8x2.5

Speed controlled by inverter; To dry the product enough.

The electric heating pipes are installed in different layers.
2.The belt speed can be controlled by the control cabinet, to control the drying time of the product in the dryer, to make sure dry the product enough.
Three drive motor for variety speed of different layer according to drying conditions. Three motor controlled by VFD.
Hot air circulation system ensure the drying properly.
Input with swing spreader machine.
All the mesh belt along with back-plate which avoid rice kernels falling outside.

Uniform and Efficient Drying

The Multi Layer Dryer MLD-1000 ensures consistent dehydration of various products such as fruits, vegetables, spices, and herbs using its 5-layer conveyor belt system and hot air circulation. High-density rock wool insulation and double sealed doors enhance energy retention, while the cross or parallel airflow effectively distributes heat for remarkable uniformity.

Advanced Safety and Control Features

Prioritizing safety, the dryer comes equipped with overload protection and an emergency stop button for prompt response to any operational issues. The computerized control cabinet facilitates precise temperature management (30-150C) and automated settings, enabling smooth, efficient, and secure operation for users in multiple industries.

Customizable, Robust Design

Designed with flexibility in mind, the dryer offers adjustable conveyor speeds and custom tray sizes to accommodate different products. Its stainless steel, polished finish means it is both corrosion-resistant and easy to clean, ensuring hygiene and longevity in demanding production environments.

FAQ's of Multi Layer Dryer:

Q: How does the Multi Layer Dryer achieve uniform drying for different materials?

A: The Multi Layer Dryer utilizes hot air circulation along with a five-layer continuous belt. Combined with cross or parallel airflow and custom tray sizes, this ensures even heat distribution, guaranteeing uniform drying for diverse materials, including vegetables, fruits, spices, and herbs.

Q: What safety features are included with this dryer model?

A: This model is equipped with overload protection, an emergency stop button, and double-sealed doors. These features safeguard both operators and the machine during operation, minimizing risk and allowing immediate intervention if issues arise.

Q: When should the machine be used in the drying process?

A: The Multi Layer Dryer is intended for use after cleaning and sorting raw materials. It efficiently dries items to a specified moisture level, making it appropriate for food processing, pharmaceuticals, and chemical industries at the production or post-harvest stage.

Q: Where can this dryer be installed, and is there installation support available?

A: The dryer is suitable for installation in commercial and industrial settings, such as food processing plants, herbal production facilities, and pharmaceutical environments. Onsite installation guidance and support are provided to ensure optimal setup and integration.

Q: What is the operating process of the Multi Layer Dryer?

A: Operators load prepared material onto custom trays, set the desired speed and temperature through the computerized control panel, and monitor drying via the control cabinet. Exhaust and conveyor accessories assist in handling and maintaining product quality throughout continuous operation.

Q: What are the main advantages of using this Multi Layer Dryer?

A: Key benefits include highly efficient drying with energy savings, low noise (<70 dB) operation, robust stainless steel construction, customizable trays and speeds, uniform dehydration, and easy maintenance, making it ideal for large-scale industrial applications.
